Face-Lit Channel Letters, Face/Back-Lit Channel Letters and Reverse/Halo-Lit Channel Letters, Sign America manufactures them all. Call today to talk with an estimator.

Face-Lit channel letters

Face/Back-Lit Channel Letters
Face-Lit Channel Letter Sign
Face/Back-Lit Channel Letter Sign
  • Our Face-lit and Face/Back-Lit Channel Letters are UL Listed.
  • Standard channel depths are 3”, 3.5”, 4”, and 5”. Custom depths are also available.
  • Letters can be stapled, riveted or welded and constructed using .040 to .080 aluminum.
  • Many standard factory pre-painted colors to choose from or we can custom paint any color.
  • Acrylic or polycarbonate faces available with many standard colors.
  • Polycarbonate backs for face/back-lit letters.
  • Faces with digital prints or vinyl available.
  • Trimcap, aluminum retainers or trimless letters available.
  • Many standard colors of trimcap are available, or we can custom paint any color.
  • Lighting can be either LED or Neon.
  • Any letters can be illuminated or non-illuminated depending on customer need.
  • Letters can be flush to wall, raceway, or wireway mounted.
  • Letters can have flat backer panels or custom designed cabinets.
  • Mounting patterns supplied for flush to wall and wireway methods.
We supply all electrical components, necessary for installation, with all UL Listed channel letters. We do not, however, supply what is needed for final connection to the electrical supply.
Mounting Guides (.pdf format): REVERSE-LIT | RACEWAY MOUNT | REMOTE

Halo lit channel letter sign Reverse-Lit Channel letters
Reverse/Halo-Lit Channel Letter Signs
  • Our Reverse/Halo-Lit Channel Letters are UL Listed.
  • Standard channel depths are 2”, 3”, 3.5”, 4”, and 5”. Custom depths available.
  • Letters are welded or LORD glued depending on aluminum thickness.
  • Letters can be constructed using .040 up to .125 aluminum.
  • Any letters using .063 to .125 aluminum will be painted letters.
  • Letter backs will be polycarbonate material.
  • Letters with digital print or vinyl faces available.
  • Letters can be LED, Neon, or non-illuminated.
  • Letters can be wall, raceway, or wireway mounted.
  • Letters can have flat backer panels or custom designed cabinets.
  • For raceway/wireway mounting a backer panel should be used.
  • Mounting patterns supplied for wall/wireway methods.
We supply all electrical components, necessary for installation, with all UL Listed channel letters We do not, however, supply what is needed for final connection to the electrical supply.
